Mittwoch, 16. November 2016

ArcadeForge Arcade Compact Bartop Artwork

Hey,

 do you like this?

This is a common Arcade Compact Bartop Artwork for our ArcadeForge Bartop Design.

Freitag, 11. November 2016

Arcadeforge Metal Slug Bartop with Stand




Find here some nice pictures of our Metal Slug Bartop with stand. This bartop comes with 645 awesome games.

Dienstag, 18. Oktober 2016

Ghost'n Goblins Bartop by ArcadeForge




Ghost'n Goblins Bartop by www.arcadeforge.de

Donkey Kong Bartop from ArcadeForge




Find this awesome at www.arcadeforge.de

Street Fighter Ultra Edition Widebody Bartop by Arcadeforge

Street Fighter Ultra Edition Widebody Bartop by www.arcadeforge.de

Can play xbox one, xbox360, PS3, PS4

Metal Slug Wide Body Bartop


Made by a customer, the widebody Bartop kit from www.arcadeforge.de

Galaxian 2 Player 6 Button Bartop by ArcadeForge


Find this bartop at www.arcadeforge.de

Amiga Racer Bartop by ArcadeForge

Find this bartop at www.arcadeforge.de

Neogeo Red Bartop by ArcadeForge

Find this bartop at www.arcadeforge.de

ArcadeForge Bubble Bobble Bartop

Find this bartop on www.arcadeforge.de

Donnerstag, 22. September 2016

Raspberry pi with native 15 khz playing pulstar on arcade cab

Here are some pictures of Mr.  Do newest development. The raspberry pi native with 15khz Jamma interface. Plug the pcb on and play your roms on your arcade cab.

No lagging hdmi, vga,  cga adapter,  no lagging usb Adapter. No extra cost for adapter...

Just PiJamma pcb and start playing.

We are taking pre order. Get in touch via arcadeforge.net contact form.

Thanks

Donnerstag, 26. Mai 2016

Bartop Ghosts'n Goblins by ArcadeForge the control panel

Find here all steps for making the ArcadeForge Bartop Control Panel with artwork.

The Artwork is printed on adhensive foil.

The control panel is assembled in sandwich technique.

-- Top Acryl Layer 2mm
-- Medium Artwork on adhensive foil
- Bottom Aluminium 1,5mm







In  the next steps one see the joysstick and buttons assembled.




Bartop ArcadeForge Ghosts'n Goblins

Hey, find here some pictures of my new Ghost'n Goblins Arcade Bartop build. The bartop Diy Kit is available on

http://arcadeforge.net/Arcade-Bartop/ArcadeForge-Bartop-Selbstbau-DIY::89.html


The enclosure is made of Mdf with primer foil and is ready for paint. So I've saved the steps for sanding and primer. Normally I take white chipboard, which has a lacquered surface already. No need for painting at all. Both are available at the page http://arcadeforge.net/.../ArcadeForge-Bartop-Selbstbau...

The Bartop was painted in dark blue.


Look here. So, I've put red T-Molding. I think the red will give the overall dark blue cabinet color a good contrast. The side parts have molding cut and rounded corners with wide angle. So the molding is more simple to attach and no strong bending is needed.



The edges I've designed that there are no open visible edges at all. What means Gehrung on English...?

Here's the light box. Speaker and led stripe will put there. I've foreseen a closed box with two holes for cables. Due to the closed box no light emissions of the leds can mirror on the screen or bezel. smile emoticon
n back panel one see some holes. Two holes are for fans, if needed. Two holes are for usb plugs, one hole for external vga interface
Ie if external tv want to be connected. Another idea was to connect another bartop that to play against each other on two bartop...just an idea. The other hole is for psu with on and off switch


That for today.
